Name: High-Strength Tungsten Carbide Molds Wear Heat Resistant Long-Lasting for Precision Electronics Automotive Components
Brand: Chongqing Henghui Precision Mold Co., Limited
SKU: Customized
Price: 1.00 USD
Availability: InStock

Nhà > các sản phẩm > cacbua vonfram chết >

High-Strength Tungsten Carbide Molds Wear Heat Resistant Long-Lasting for Precision Electronics Automotive Components

Miniature Button Head Micro Screws

Stainless Steel 410 Micro Screws

Place of Origin:

CHINA

Hàng hiệu:

Heng Hui

Chứng nhận:

ISO9001

Model Number:

Customized

Liên hệ với chúng tôi

Yêu cầu Đặt giá

High-Strength Tungsten Carbide Molds Wear Heat Resistant Long-Lasting for Precision Electronics Automotive Components

Chi tiết sản phẩm

Product name:

Tungsten Carbide Die

Size:

Customized

Function:

Multifunctional

Delivery time:

15~20 Days

Payment term:

T/T

Mould Life:

250000-300000shots

Application:

Industry

Surface Finishing:

Custom Surface Texture

Điều khoản thanh toán và vận chuyển

Minimum Order Quantity

10PCS

Giá bán

USD+2-1PCS

Packaging Details

Carton Box

Delivery Time

10-20Days

Payment Terms

T/T

Supply Ability

1000PCS+Month

Sản phẩm liên quan

Tungsten Carbide Molds: Precision Engineering For Industrial Applications High-Performance Tooling Solutions With Superior Wear Resistance

Nhận được giá tốt nhất

+8613983025528

sales1@citool.com

86-023-60338218-60338218

Liên hệ ngay bây giờ

Mô tả sản phẩm

Products Description

Insert Material:We can suggest different carbide material according to different usage.

	Item	Co	Grain Size	Density	Hardness	TRS	Impact Strength	Application
Mediun-Grained		Co%	μm	g/cm²	HRA	Kgf/mm²	Kgf/m-cm²
	KG2	6.50%	2~3	14.90	90.5	320	0.28	Drawing die
	KG3	9%	2~3	14.61	89.3	340	0.52	Extrusion die
	KG5	12%	2~3	14.31	88.3	340	0.58	Extrusion die
	KG6	14%	2~3	14.12	87.3	320	0.65	Extrusion die
Coarse-Grained	ST6	15%	3~6	13.80	86.0	270	0.78	Stainless steel
	ST7	20%	2~6	13.40	85.3	270	0.80	Stainless steel
	EA65	18%	2~6	13.73	85.0	300	0.80	Carbon steel screw/cutting die
	VA80	20%	3~6	13.58	84.0	280	0.85	Impact resistance
	VA90	22%	6~9	13.39	82.5	240	0.90	Impact resistance
	EA90	24%	2~6	13.22	82.8	270	0.90	Impact resistance

Case Material:Our main case material is H13(SKD61) HRC46-48

SKD61(H13)
Chemical Composition	C	Si	Mn	P	S	Cr	Mo	V	W
Content (%)	0.39	1.15	0.44	0.021	0.007	5.12	1.3	0.94	0.06
	Cu	Ni
	0.05	0.06

Surface Treatment:TiN / TiAlN

Process
